LV429387
Giá: Liên hệ
Mã sản phẩm: LV429387
Share
| device short name |
MX
|
|
|---|---|---|
| product or component type |
Voltage release
|
|
| device application |
Control
|
|
| range compatibility |
Compact NSX
EasyPact CVS PowerPact Multistandard |
|
| voltage release type |
Shunt trip release
|
|
| [Uc] control circuit voltage |
208...277 V AC 60 Hz
220...240 V AC 50/60 Hz |
| control signal type |
Impulse
Maintained |
|
|---|---|---|
| impulse duration |
>= 20 ms
|
|
| threshold tripping voltage |
0.7...1.1 x Un opening
|
|
| supply inrush power |
10 VA
|
|
| mounting mode |
Fixed
|
|
| response time |
50 ms
|
|
| auxiliary connection terminal |
Screw terminal0…1.5 mm²
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
| Mercury free |
Yes
|
|
| RoHS exemption information | ||
| China RoHS Regulation |
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information |
|
| Environmental Disclosure | ||
| Circularity Profile |
No need of specific recycling operations
|
| Warranty |
18 months
|
|---|
